New Design Shangqiu Tire Recycling Line For Pyrolysis Oil
Model of Pyrolysis plant:
| Model | Reactor size | Material | Handling capacity/batch | Seaworthy packing |
| LJ-8 | 2200*6000mm | Q245R /Q345R boiler steel ,16mm thickness | 5 tons | 2*40HQ |
| LJ-9 | 2200*6600mm | 8tons | ||
| LJ-10 | 2600*6600mm | 10tons | 1*40FR+1*40HQ | |
| LJ-12 | 2800*6600mm | Q245R/Q345R boiler steel ,18mm thickness | 12tons | |
| LJ-15 | 2800*7700mm | 15tons |
New Design Tire Recycling Equipment Pyrolysis To Diesel Machine
Working process:
First, the raw materials are put into the reactor, and then seal
the feeding in door, later start the machine and the reactor will
be rotating and heated by coal, natural gas, wood or electricity.
When the temperature reaches the degree of 250 to 280, we will get
the crude oil, the oil steam will be continuous produced until the
temperature reaches 350-460°C; oil steam will flow through oil gas
separator, light component will enter the condensers and meanwhile
the heavy oil will be discharged automatically into in heavy oil
tank. The liquefied part will be condensed as crude oil, and the
part which cannot be liquefied will be transferred by the water
seal back to the burning chamber to be reused as heating material.
End of Product from scrap tire oil refining machine:
NO. | Name | Percentage | Usage |
1 | Tyre oil | 40%~45% | * can be sold directly as fuel. * can be refine to diesel and gasoline by oil distillation plant |
2 | Carbon black | 37% | * can be sold directly. * can be refined by carbon black processing machine to make it finer (1500mesh finer). *can be made into pellet by pellet machine |
3 | Steel wire | 13% | *can be sold directly as steel or iron. |
4 | Waste gas | 5% | * can be recycled to heat up the reactor |
Pyrolysis plant Installation: We will be in charge of arranging our engineer to go to your place to guide the installation and train your workers how to operate the waste tire recycling to fuel oil machine,and you will be in charge of the food, accommodation and round air tickets.
Tire oil recycling machine Land requirement: 300sq meters(10m*30m)
Exporting Experience:
America: | Brazil, Canada, Colombia, USA, |
Middle East: | Dubai, Jordan, Saudi Arabia, Turkey |
Europe: | Albania , Bosnia and Herzegovina |
Asia: | Afghanistan, India, Malaysia, Pakistan, Philippines, South Korea, Vietnam, Myanmar, Thailand |
Africa: | Ghana, Mozambique, Zambia |
|
|
